Ducato, Jumper, Relay, Boxer X230 (1994-2002) | Dunlop

£421.00 inc. VAT

This kit fits the Fiat Ducato, Citroen Relay and Jumper and Peugeot Boxer vans made between 1994 and 2002 (X230), as well as any motor home based upon these vans in the same time period.  It is a rear-end load support kit, fitted to the rear in addition to the standard spring.

The kit can be supplied with Schrader (tyre) valves for inflation, or with on-board air to inflate/deflate at just the touch of a button (see the ‘Options’ tab for more info).

In stock


Please check the OPTIONS tab below (when present) for further explanation of Management options


Management *

Please note that other specifications are available on request. Please contact us for a personal specific quotation.

Product price
Additional options total:
Order total:

Description

This is a Dunlop air suspension kit. Based on several decades specialising in air suspension, we believe that this is the highest-quality load support kit on the market for these vehicles. The kit:

  • is a practical bolt-on installation which is rated as DIY or local garage fit
  • Improves stability and handling and reduces roll
  • Recovers lost suspension motion to improve ride quality
  • Lifts sagging vehicles to reduce or prevent grounding
  • Is superb for help with towing
  • Can help pass an MOT if your vehicle is low
  • Can help re-rating for heavier capacity on some vehicles

It includes:

  • Electroplated quality metal brackets made from high grade 5mm steel in most cases
  • Properly-secured brackets that won’t slip, fracture or come adrift.
  • Proper automotive-grade air springs (air bags). Bags have at least six inches of lift potential
  • Specifically-designed brackets, mounted at points able to take the load
  • A five-year extended warranty (terms apply)
  • Full EU certification for legal use in EU and other countries subject to equivalency

If you are unsure of the correct fitment, please email or call.



Specifications

Bracket Construction:- 5mm Electroplated Steel
Bag Diameter:- 7 inch (170mm)
Bag Style:- Double Convoluted
Kit Weight:- 11 Kg
Vehicle Model Dates:- 1994-2002
Axle/Beam Dimensions:- Square
Vehicle Driven Wheels:- Front
Minimum Pressure:- 20 psi
Maximum Pressure:- 105 psi



Video

This is a generic video clip to show the nature of the kits. Actual kit contents may vary. Many of the kits are generally similar and therefore please check out some of the other videos for an idea of what the kits look like, and you may browse videos by clicking here. If you need further information please do email or call.

Delivery

Delivery for full air suspension kits are free to mainland UK. Delivery to the Highlands, islands and overseas will be charged however, so please call us for a quote.

Please get in touch to find out an exact date for dispatch. We sell items outside the UK but website postage prices are for the UK. Additional charges will be levied for non-UK and they will be invoiced separately. Alternatively, international customers can email their requirements to ENQUIRIES@AIRRIDE.UK and we can raise an invoice including international postage.

Please do call if you need more information, or to check on stock as it can change quickly. Please do not assume that something is still in stock if you last checked on a different day to ordering.



Warranty

AirRide Sales Limited offer a warranty on Dunlop air conversion kits for a period of 5 years from time of purchase. This warranty is limited to the original purchaser and subject to registration at the time of fitting. If you fail to register then a 1 year warranty is offered.

Dunlop kits are the very best fitting kits on the market. If the kit does not appear to fit – STOP and call us, as a vehicle misidentification may have occurred. Kits will be accepted for return and exchange only if they are undamaged. The buyer must cover the return postage.

Options

Heavy motorhomes with fixed loads are often fitted with simple control systems, such as Schrader (tyre) valves or Schrader valves and a gauge block. These work very well for vehicles carrying a fixed load/weight.

When the load in your motorhome varies significantly, On-Board Air (OBA) is normally required. This enables you to get the very best from your kit at all times. OBA allows the ride height to be adjusted for road, weather and load conditions, and for those experiencing grounding conditions it allows the absolute maximum lift to be achieved when needed (for instance on ferries, petrol stations and rough site entrances). The vehicle can then be returned to the most comfortable setting.

OBA is also great for towing, where loads are added or removed, or for commercial vehicles that start the working day at one weight and end it at another as deliveries are completed.

OBA packages come in various specifications as outlined below. If in doubt, please contact us via e-mail or phone.

Schrader valve kits

The simplest kit available. One fitting at the airbag, a length of line and a Schrader (tyre) valve at the other end. The valve can be fitted anywhere convenient to the user and can be inflated anywhere a tyre can be inflated (e.g. garage, petrol station).

Recommended for: Vehicles with a fixed load that does not alter and users who want an entry-level system. Ideal for motorhomes because they are always very heavy vehicles but the weight does not usually vary considerably. Users need to find an air source (i.e. at a garage or petrol station) to adjust the pressures (emergency tyre inflators rarely last if asked to inflate air suspension regularly.)

Schrader valve gauge blocks

A gauge block with two Schrader valves and two gauges. No moving parts to go wrong, such as taps or levers. Pressure can be monitored from the gauge block, which can be fitted anywhere convenient. Several versions available.

Recommended for: Vehicles with a fixed load as above but with two gauges for those who always want to know the pressure in the bags.

Budget Duty OBA

Includes a 10% duty cycle compressor, maximum 105 PSI. Comes with an OBA hook-up kit to match the compressor, which comes with an on/off button to get to pressure. Also comes with a cross-locking mini valve. Please note that although the left and right air bags are independent, they cannot be set to different pressures. Does not include a tank.

Recommended for: Infrequent adjustment. When the load varies, due to towing or adding payload to a commercial vehicle, air-managed solutions get the very best from the system. This is an entry-level, compressor control package.

Economy Duty OBA

Includes a low duty cycle compressor, maximum 130 PSI. Please note: The left and right air bags are independent but cannot simply be set to different pressures at the touch of a button. Higher specification than the entry-level kit, making this kit very good value for money.

This kit is simple to install and operate. As the video below shows, it has a single button to simultaneously lift both sides. To deflate the air and lower the vehicle requires use of the Schrader valves at the bottom of the controller.

Recommended for: Users who want a better controller with a heavier-duty compressor but who perhaps don’t adjust the suspension every time they use it and don’t mind waiting 30-40 seconds to lift or drop the vehicle.

Standard Duty OBA

Includes a low duty cycle compressor, maximum 130 PSI, small steel tank, twin-button-and-gauge controller and an OBA hook-up kit to match the compressor. Please note: The left and right air bags are independent and can be set to different pressures. Used for regular adjustment. The compressor is pre-wired with only the connections to the switching relay and three to the vehicle to be made. Four buttons allow users to lift or drop the vehicle from the control panel in a few seconds.

Recommended for: Users who regularly adjust the suspension and want to do so in a few seconds. If you have grounding issues on a motorhome then this is the controller for you. This is the minimum recommended for commercial vehicles. Ideal if you have a steep drive, problems with ferries or regularly change the weight of your vehicle.

Premium Duty OBA

Includes a 100% duty cycle compressor, maximum 200 PSI, 200 PSI tank, twin paddle/gauge controller. Used for daily adjustment. Top general spec. This is a far higher spec than the Standard Duty but essentially the same principle. Single, combined button for up and for down, and a single gauge for both left and right (twin needle).

Recommended for: Ideal control for commercial use and for motorhome users who just want the confidence from fitting the best compressor and a simpler/smarter controller. If you adjust multiple times per day then this is the ideal option.

Ultimate OBA

Includes a 100% duty cycle compressor, maximum 200 PSI, 200 PSI tank. Used for daily adjustment. Top spec, includes computer controller with programmable pre-sets and standard height adjustment for general running but can be overridden when conditions require.

This system can adjust up to four corners and, as the name suggests, is the ultimate controller. Everything is located in one integrated unit, which makes installation simple, and the remote function from any Android or Apple phone or tablet is a real bonus.

Recommended for: Users who want the best computer we offer and a remote control. Anyone who wants the best On-Board Air money can buy should go for Ultimate OBA.

If you need further clarification or your needs are not listed, please do call 0800 772 0315 or email enquiries@airide.uk and we will be very happy to help, or to raise a personal quotation.
